| Derrick: | 210 ft x 80 ft x 60 ft; 1,250 st main & 1,000 st aux |
| Drawworks: | 2 x NOV Active Heave Drawwork, 2,500 kips single speed gear driven by 6 x 1,150 HP AC motors with 2 1/8” line |
| Top Drive: | 2 x NOV TDX-1250, 1250 ST hoisting, 1,200 ST rotating, torque 90,740 ft.lbs |
| Rotary: | 1 x NOV RST 755 (75-1/2”) hydraulic (Main); 1 x NOV RST 605 (60-1/2”) hydraulic (Auxiliary) |
| Iron Roughneck: | Hydratong MPT TF-975 w/ TE-1190 (2 ea.); 147,000 ft-lbs. |
| Riser Tensioner / Stroke: | (8) NOV SWRT-250-50; 225 kips/ea; Wire line travel of 50ft stroke |
| Riser Details: | NOV-Shaffer 21" OD, FT-DGD 90 ft joints Class H 3 1/2 M. lbs couplings & 15k 4.1/2" ID C&K lines - 10,000 ft; 58" buoyancy |
| BOP: | 6 ram cavities: 2 x NOV-Shaffer NXT 18¾" 15k triple; GE-Vetco SHD H4 18¾" 15k wellhead |
| LMRP: | 2 x NOV-Shaffer 18¾" 10k annular; GE-Vetco ExF H4 18¾"15k High Angle Release LMRP connector |
| Control System: | NOV-Shaffer 6th Gen. Multiplex Control System suitable for 12,000 ft |
| Pipe Handling System: | 2 x Hydra-Racker System HR-IV (for 3.1/2” to 20” tubulars), 2 x Hydratong MPT-200 (for 3.1/2” to 9.3/4” tool-joints) |
| Solids Control System: | NOV-Shaffer 6th Gen. Multiplex Control System suitable for 12,000 ft |
| Diverter: | NOV-Shaffer 21 1/4" CSO for 75 1/2” Rotary table, 500 psi |
| Tree Storage/Handling: | 1 x BOP trolley with skid rated 540 tons; 2 x 240 ton BOP gantry crane with dual lifting hoists, 2 x X-mas tree skids rated 120 tons, 1 x Multi-purpose cart rated 1,000 tons (lower BOP, X-mas tree handling, riser hang-off, DGD pump) |
| Cranes: | (4 x 85 MT electro-hydraulic knuckle-boom cranes at 18 m (59 ft) radius, 1 x 9 MT electro-hydraulic tubular handler at 22.3 m (73 ft) radius on forward pipe deck |
| Mud Pumps: | 4 x NOV 14-P-220, 7,500 psi |
| Engines: | HIMSEN engines 6 x 8,000 KW at 720 RPM, Tier 2 compliant, each driving 1 x 7,760 kW 11kV ABB generators |
| Station Keeping: | Kongsberg DYNPOS AUTRO System for DP-3 Operations |
| Thrusters: | 6 x Rolls Royce Aquamaster fixed pitch Azimuthing in water removable thrusters |
