General
| Rig Type | Semisubmersible |
| Rig Design | F&G ExD Millennium |
| Year Entered Service | 2009 |
| Builder | Jurong Shipyard PTE LTD |
| Flag | Marshall Islands |
| Classification | ABS +A1, Column Stabilized Drilling Unit, Circle E, +AMS, +DPS-2 |
| MODU Code | 1989 |
| Overall Length | 244 ft long x 244 ft wide |
| Draft | 59 ft Drilling, 44 ft Transit |
| Airgap | 28 m (91.9 ft) at drilling draft |
| Displacement | 46,700 t Operating |
| Variable Deck Load | 8,100 t (drilling), 5,600 t (transit) |
| Transit Speed | 6 knots |
| Water Depth | 10,000ft |
| Drilling Depth | 40,000ft |
| Accommodation | 164 people |
| Hook Load | 2.0 MM lbs |
| Moonpool | 135 ft x 29.5 ft |
Storage Capacity
| Liquid Mud | 18,986 bbls |
| Base Oil | 4,718 bbls |
| Brine | 4,801 bbls |
| Bulk Cement | 17,057 cuft |
| Bulk Bentonite | 8,828 cuft |
| Bulk Barite | 8,828 cuft |
| Sack Storage | 6,100 sacks |
| Fuel | 21,043 bbls |
| Drill Water | 14,613 bbls |
| Potable Water | 10,676 bbls |
Drilling Equipment
| Derrick | Aker MH AS Quad 210ft high with 46ft x 52ft base, hook load capacity 2,500 kips |
| Drawworks | Wirth GH-4500, three AC motors, 3,150hp total output, with 2” drilling line |
| Motion Compensator | Active/Passive compensator, 1,500 kips capacity with 25 ft stroke |
| Rotary Table | Wirth RTSS, 60 ½”x 2000kips static |
| Top Drive | 1x Aker MH Vertical Pipe Handler 3 ½” to 14” Independent offline standbuilding 3 ½” to 14” |
| Fingerboard Capacity | P – 13,824 ft up to 5-7/8” OD DP – 26,112 ft up to 6-5/8” OD BHA – 2,362 ft up to 9 ½” OD CSG – Adjustable fingerboard up to 14” OD |
| Mud Pumps | 4x Wirth TPK AS 2,200hp triplex, 7,500 psi |
| Solids Control System | 6x Derrick / FLC-503 VE |
| Iron Roughneck | 2 x MHWirth RNX (main + offline standbuilding) |
Subsea Equipment
| Diverter | Vetco KFDS-CSO 60-1/2” Max Bore Size 20", Working Pressure 500 psi |
| Dual BOP | No |
| BOP Stack | Cameron TL 18 ¾” 15,000psi six-ram preventer |
| LMRP | 2 x Cameron DL 18 ¾” 10,000psi annular preventers |
| C&K Manifold | 15k |
| Marine Riser | Cameron 21” Load King, 75ft length, vertical riser storage bay for 99 joints (7,425 ft) |
| Tensioners | 6x 600 kips AKER MH AS, each 416.5 sT with 50 ft stroke |
| XT Carts | 1x X-Mas Tree Trolley with 150 mT capacity |
Cranes
| Main Cranes | 2 x 100 ton Seatrax S10832 with 170 ft boom 1 x 15 ton Maritime Hydraulics knuckle-boom |
| Subsea Cranes | N/A |
| X-Mas Tree / BOP | 1x MH gantry / 1x MH Gantry |
| Other | 1 x MH Vertical riser handling gantry |
Power Generation
| Electrical Power | 8 x 4,800 kW ABB / AMG 0710Lt08 LSE 900rpm |
| Emergency Power | 1 x 1,300 kW CAT 3512, 1,800 rpm |
Station Keeping / Propulsion System
| Mooring System | N/A |
| Mooring Winches | N/A |
| Thrusters | 8x Rolls Royce Ulstein Aquamaster, 3800 kW variable speed, fixed pitch, fully azimuthing |
| DP System | Kongsberg SDP-32 System for DPS-2 Operations |
Other Information
| MPD | Ready (hard piping installed) |
| Burner Booms | Deployable and retractable |
| Dual Well Centers | No |
| Red Zone Management | Altave Intelligent Monitoring Video Analytics (rig floor and main deck) |
| On the Go | Yes |
